8" COAXIAL FERRITE COMMON HF\LF MAGNET STEEL BASKET DRIVER
LF 200W / HF 35W AES, 8ohm, LF 96dB / HF 103,5dB, 75-20000Hz
LAVOCE CSF082.00K-8
8" COAXIAL FERRITE COMMON HF\LF MAGNET STEEL BASKET DRIVER
LF 200W / HF 35W AES, 8ohm, LF 96dB / HF 103,5dB, 75-20000Hz
zł596.16
Tax included
Description
8" COAXIAL FERRITE COMMON HF\LF MAGNET STEEL BASKET DRIVER
- 2 INCH LF EDGEWOUND CCA VOICE COIL
- 1.4 INCH HF CCA VOICE COIL
- 96 dB/SPL SENSITIVITY
- 400 WATT PROGRAM POWER HANDLING
- FEM OPTIMIZED COMMON MOTOR, PHASEPLUG AND DIAPHRAGM
- 75-20000Hz FREQUENCY RANGE
- 100° NOMINAL COVERAGE
- POLYIMIDE HF DIAPHRAGM
- DOUBLE ALUMINIUM DEMODULATING RING
- COMPACT AND LIGHTWEIGHT DESIGN
Product Details
VLR07080
4 Items
Data sheet
- Nominal diameter
- 8" (200mm)
- Nominal impedance
- 8 Ohm
- AES power rating
- LF 200W / HF 35W
- Sensitivity
- LF 96dB / HF 103,5dB
- Frequency range
- LF 75-5500Hz / HF 1500-20000Hz
- Resonance frequency
- 76Hz
- Total Q-factor
- 0,35
- Voice coil diameter
- LF 2" / HF 1,4" ( 50mm / 35mm )
- Magnet material
- ferryt / ferrite
- Net weight
- 3kg
